| Particular | Size |
| Wire Diameter S.W.G. (MM) | 6-4/(4.0 – 6.0 ) |
| Nail Length Inch (mm) | 2.00″-6.00″( 50 – 152 ) |
| Max. Speed (Nails/Minutes) | 150 |
| Approx net weight Kgs | 2500 Kgs. |
| Approx Gross Weight Kgs | 2750kGS.. |
| Power Required H.P. | 10HP |
| Case Size (m.m.) | 245 x 1500 x 1900 |
| Approx. Floor Area (m.m.) | 1350 x 1270 |
| PRODUCTION ESTIMATE | PRICE ESTIMATE |
|---|
| Length in inch | Thickness in SWG | Thickness in MM | Kg in 8 hour | Average 75% Efficiency | Rate (Rs.) | Packaging charges (Rs.) |
| 1.50 | 4 | 5.90 | 506 | 1011KGS. | 9,50,000 | 18000 |
| 2.00 | 4 | 5.90 | 653 | 1011KGS. | 9,50,000 | 18000 |
| 2.50 | 4 | 5.90 | 800 | 1011KGS. | 9,50,000 | 18000 |
| 3.00 | 4 | 5.90 | 948 | 1011KGS. | 9,50,000 | 18000 |
| 4.00 | 4 | 5.90 | 1243 | 1011KGS. | 9,50,000 | 18000 |
| 5.00 | 4 | 5.90 | 1539 | 1011KGS. | 9,50,000 | 18000 |
| 6.00 | 4 | 5.90 | 1833 | 1011KGS. | 9,50,000 | 18000 |
| 5.00 | 6 | 4.88 | 1013 | 1011KGS. | 9,50,000 | 18000 |
| 4.00 | 8 | 4.06 | 563 | 1011KGS. | 9,50,000 | 18000 |
