| Particular | Size |
| WireDiameter S.W.G. (MM) | 10-6G (2.64 – 4.90mm) |
| Nail Length Inch (mm) | 1″-4″ (25 – 125) |
| Max. Speed (Nails/Minutes) | 250 |
| Approx net weight Kgs | 1250 KGs. |
| Power Required H.P. | 5.00HP |
| Case Size (m.m.) | 1400 x 1000 x 115 |
| PRODUCTION ESTIMATE | PRICE ESTIMATE |
|---|
| Length in inch | Thickness in SWG | Thickness in MM | Kg in 8 hour | Average 75% Efficiency | Rate (Rs.) | Packaging charges (Rs.) |
| 5.00 | 6 | 4.88 | 1300 | 1011KGS. | 9,50,000 | 18000 |
| 4.00 | 6 | 4.88 | 1040 | 1011KGS. | 9,50,000 | 18000 |
| 2.50 | 8 | 4.06 | 775 | 1011KGS. | 9,50,000 | 18000 |
| 2.00 | 8 | 4.06 | 675 | 1011KGS. | 9,50,000 | 18000 |
| 1.50 | 10 | 3.26 | 328 | 1011KGS. | 9,50,000 | 18000 |
| 2.00 | 10 | 3.26 | 476 | 1011KGS. | 9,50,000 | 18000 |
| 2.50 | 10 | 3.26 | 530 | 1011KGS. | 9,50,000 | 18000 |
| 2.00 | 12 | 2.64 | 297 | 1011KGS. | 9,50,000 | 18000 |
| 4.00 | 2 | 4.06 | 950 | 1011KGS. | 9,50,000 | 18000 |
