| Particular | Size |
| WireDiameter S.W.G. (MM) | 8-12G(2- 2.64 MM) |
| Nail Length Inch (mm) | 1″-3″ (25-75 MM) |
| Max .Speed (Nails/Minutes) | 350 |
| Approx net weight Kgs | 975 Kgs. |
| Approx Gross Weight Kgs | 1140 Kgs. |
| Power Required H.P. | 3.00 HP |
| Case Size (m.m.) | 1315 x 1120 x 1130 |
| PRODUCTION ESTIMATE | PRICE ESTIMATE |
|---|
| Length in inch | Thickness in SWG | Thickness in MM | Kg in 8 hour | Average 75% Efficiency | Rate (Rs.) | Packaging charges (Rs.) |
| 4.00 | 8 | 4.06 | 1150 | 616KGS. | 3,70,000 | 8000 |
| 3.00 | 8 | 4.06 | 985 | 616KGS. | 3,70,000 | 8000 |
| 2.50 | 9 | 3.66 | 757 | 616KGS. | 3,70,000 | 8000 |
| 2.00 | 9 | 3.66 | 525 | 616KGS. | 3,70,000 | 8000 |
| 1.50 | 10 | 3.26 | 364 | 616KGS. | 3,70,000 | 8000 |
| 2.00 | 10 | 3.26 | 476 | 616KGS. | 3,70,000 | 8000 |
| 2.50 | 10 | 3.26 | 589 | 616KGS. | 3,70,000 | 8000 |
| 2.00 | 12 | 2.64 | 330 | 616KGS. | 3,70,000 | 8000 |
| 1.50 | 13 | 2.34 | 225 | 616KGS. | 3,70,000 | 8000 |
| 1.25 | 14 | 2.03 | 143 | 616KGS. | 3,70,000 | 8000 |
